Item

Content

labelling method and features）

Fluorescent labeling(       )

excitation wavelength(nm):

emission wavelength(nm):

colloidal gold labeling:    (     )

latex labeling:   (        )

C/T lines

2 lines(   )   3 lines(   )   4 lines(    )

Screen

3.5 inch LCD touch screen

Printer

(     )no thermal printer

(     )

Built-in thermal printer needed

Standard curve storage

- (     ) (IC chip)

- (     ) (1-dimensional   code scanner)

- (     ) (2-dimensional   code scanner)

- (     )( download from PC )

Sample ID entry

- (     ) (keyboard)

- (     ) (external scanning gun)

- (     ) (automatic generation)

Test strip barcod

- (     )(no need)

- (     )(built-in 1- dimensional bar-code recognition unit (mounted in the side window)

- (     )(built-in 2- dimensional bar-code recognition unit (mounted in the side window) )

Power supply

External regulator

Test strip size

Drawings provided by customers

Test channels

single channel

Peak value

Automatic recognition

Interval between lines (center distance)

>3mm

Test line width

0.8-1.2mm

Test window area

Length<13mm, width 3-5mm, Distance between the edges of the test window and the nearest test line>2mm

Test period

<5 second

Sensitivity

<0.5%

repeatability

<1%，

According to the formula CV=standard deviation/average

Environment temperature

＋5~＋40℃

Environment humidity

10%-70%

Storage temperature

-20~＋70℃

Storage humidity

0~90%

LIS connection

Detector-PC-LIS

External printer

Detector-PC-external printer

Test method

Quick test and standard test

Software interface requirements:

According to the screen specification and customer requirements

Data storage

>10000, can store the sample detection information and   QC product information, including the date, sample ID, test result etc.

workflow

customized

PC supporting software

Connect to the detector, can analyze ,upload and download test data

Use lifetime

Quality guarantee period ：1 year

Use life time：>3 years
